S1F3 Magic Box Android Terminal

Castles Technology’s newly designed S1F3 MAGIC BOX offer multifunctional capabilities and streamlines customer’s shopping experiences. S1F3 MAGIC BOX supports Ethernet, RS232, and USB.

download PDF

Working with S1F3, it provides a perfect solution to simplify the shopping process and successfully make the payment easier.

Technical specifications

Processor	ARM A53 Quad-Core 2.0GHz + Secure Processor
Memory	Flash/RAM 32GB/2GB \| Micro-SD
Operating System	Android 12
Display	5.5” TFT Color Display (1440 x 720) with Capacitive Touch Screen
Card Reader	Magnetic Stripe, Smart Card, Contactless, SIM, SAM
Communication Interface Options	Wire, Wireless
Audio	Speaker \| Microphone
Keypad	Virtual Keypad / PIN on Glass
Camera	5MP Auto Focus Rear Camera \| 2MP Fixed Focus Front Camera (optional)
Printer	Paper Roll Size: 57mm (W) x Ø40mm \| Print Speed: 100mm/sec
Software	SDK \| KMS \| TMS \| GDB \| CTOS library \| ISO 8583 library \| Crypto library
Crypto	TRNG \| DES \| TDES \| AES \| RSA \| MK/SK \| DUKPT
Power Supply	DC Adapter 5V/2A
Dimensions (L x W x H)	200 x 82.73 x 56.65 (mm)
Weight	380 g
Operating Temperature	-10°C to 50°
Storage Temperature	-20ºC to 70ºC
Operating Humidity	5% to 90% non-condensing
Storage Humidity	5% to 90% non-condensing
Certification	PCI PTS 6.x \| EMV L1/L2 \| payWave \| PayPass \| ExpressPay \| D-PAS \| Interac Flash \| J/Speedy \| FeliCa \| QuickPass \| TQM
Optional Accessories	5V/2A Power Adapter, Magic Box
