S2F – Hybrid POS/Selfcheckout

S2F – Hybrid POS/Selfcheckout

Meet S2F – a new form of SCO based on our best-seller S2P.

Meet S2F – a new form of SCO based on our best-seller S2P.
More stylish, more flexible, high-performance, full-featured
Meet the functional needs of small spaces
Concise and elegant lines, in line with the business tone

Technical specifications:

Windows 10 IOT - LINUX		Android 9.0
Intel® Celeron 3865U/3867U, clock speed 1.8G, Dual-core Intel® Core i3-7100U, clock speed 2.4G, Dual-core Intel® Core i5-8250U, clock speed 1.6G, Qual-core	HOST CPU	Rockchip RK3399, Dual-core Cortex-A72 up to 1.8GHz, Quad-core Cortex-A53 up to 1.4GHz
DDR4 SO-DIMM slot x 1 default 4GB, max. 16GB	HOST MEMORY	LPDDR3 4GB
M.2 2280 slot x 2 SSD default 128G, max. 512GB	HOST CAPACITY	eMMC 32GB
Support 10/100/1000Mbps Ethernet Support 2.4G/5G WiFi, 802.11 b/g/n/ac agreement.	HOST NETWORK	Support 10/100/1000Mbps and Ethernet Support 2.4G WiFi, Wi-Fi 802.11b/g/n agreement.
15.6", resolution 1920*1080	MAIN SCREEN DISPLAY	15.6", resolution 1920*1080
Capacitive ten-point touch screen, Flat surface, Scratchproof, dustproof, waterproof	MAIN SCREEN TOUCH SCREEN	Capacitive ten-point touch screen, Flat surface, Scratchproof, dustproof, waterproof
15" TFT LCD, resolution 1024768 15.6" TFT LCD, resolution 19201080	SECOND SCREEN (Optional) DISPLAY	15.6", resolution 1920*1080
Capacitive ten-point touch screen, Flat surface, Scratchproof, dustproof, waterproof	SECOND SCREEN (Optional) TOUCH SCREEN	Capacitive ten-point touch screen, Flat surface, Scratchproof, dustproof, waterproof
2W * 2	AUDIO SPEAKER	2W * 2
USB 3.0 * 2,24V Power USB * 1,12V Power USB * 3, TYPE-C * 1, com * 4, LAN * 1, DP * 1,24V cash drawer * 1	INTERFACE	USB 3.0 * 2,24V Power USB * 1,12V Power USB * 3, TYPE-C * 1, com * 4, LAN * 1, DP * 1,24V cash drawer * 1
Desktop adapter input AC 110-230V 50/60HZ, Output DC 24V 5A	POWER	Desktop adapter input AC 110-230V 50/60HZ, Output DC 24V 5A
Model: Thermal direct line Speed: 250 mm/s (max) Print length: 150KM	PRINTER	Paper: width 80mm, 58mm Print width: 72mm(max) Cutter life: 1500,000times
Pixer: 1280 x 800 pixel Movement Tolerance: Up to 2.5 m/s for the best focus, UPC 13mil code	SCANNER	Pixer: 1280 x 800 pixel Movement Tolerance: Up to 2.5 m/s for the best focus, UPC 13mil code
Supports 1,2,3 tracks, conforms to ISO 7811 / 7812 standard, decoding mode F2F (FM), and head life of 800000 times	MSR	Supports 1,2,3 tracks, conforms to ISO 7811 / 7812 standard, decoding mode F2F (FM), and head life of 800000 times
