S1P2 Android Terminal

The S1P2 is a versatile Android payment PIN pad supporting all major payment methods, including magnetic stripe, Chip and PIN, contactless, and QR code with a built-in front camera. It offers both wired (USB, RS232, Ethernet) and wireless (4G LTE, Wi-Fi, Bluetooth) connectivity, making it ideal for various sectors such as retail, hospitality, banking and more.

download PDF

Featuring 13 large backlit keys for ease of use, the S1P2 is PCI PTS 6.x certified, ensuring top-tier security and reliability for businesses in need of efficient, secure payment solutions.

Technical specifications

Processor	ARM A53 Quad-Core 2.GHz + Secure Processor
Memory	Flash: 8GB \| RAM: 2GB
Operating System	Android 13
Display	4" Color Display with Capacitive Touch Screen
Card Reader	Magnetic Stripe, Smart Card, Contactless, SIM, SAM
Communication Ports	USB-A, Ethernet, RS232
Wireless	4G LTE, 3G, 2G, Wi-Fi, Bluetooth
Positioning	GPS, GLONASS, BEIDOU, GALILEO
Audio	Speaker \| Audio Jack
SIM & SAM	2 SIM \| 1 SIM + eSIM (option) \| 2 SAM
Keypad	15 Backlit Keys
Camera	Front: 0.3MP FF
Power Supply	DC 5V/2A
Dimensions (L x W x H)	179 x 78 x 23 mm
Weight	252g
Operating Temperature	-10°C to 50°
Storage Temperature	-20°C to 70°
Operating Humidity	5% to 90% Non-condensing
Storage Humidity	5% to 90% Non-condensing
Certification	PCI PTS 6.x \| EMV L1/L2 \| payWave \| PayPass \| ExpressPay \| D-PAS \| Interac Flash \| J/Speedy \| FeliCa \| QuickPass \| TQM
CasHUB Support	Yes
Optional Accessories	Cables, PIN Shield, 5V/2A Power Adapter, Magic Box
